Threading Tools

Complete threading program including taps, solid carbide thread mills and indexable inserts for UN, metric, NPT and BSPP threads.

Threading Tools series

Explore by series

Five threading tool series, each with its own application guide, tool-selection notes and RFQ checklist. Choose the series that matches your part to see configurations, materials and custom options.

01Solid Carbide Tools for Production Threading

Carbide Taps

Solid carbide taps for repeatable internal-thread production in stable machining conditions — engineered around the thread specification, workpiece material, hole preparation, machine, and production target.

9 productsView series 02Tough, Versatile HSS Threading Tools

High-Speed Steel Taps

High-speed steel taps for general machining, fabrication, repair, and production — a tough, serviceable option for standard threads and application-specific geometries.

21 productsView series 03CNC Tools for Internal and External Threads

Thread Milling Cutters

Thread milling cutters for CNC production of internal and external threads — configured around the thread specification, prepared feature, workpiece material, interpolation path, machine, and holder.

23 productsView series 04Drawing-Based Cutters for Orthopedic Component Threads

Orthopedic Thread Milling Cutters

Specialized thread milling cutters for precision thread features in orthopedic-component manufacturing — engineered from the approved component drawing, material specification, machine, and validated production process.

8 productsView series 05Gauges and Inspection Tools for Thread Verification

Thread Measurement Tools

Thread measurement tools for checking internal and external thread features — specified around the thread standard, designation, tolerance class, acceptance method, and quality-system requirements.

Made to your drawingView series

Not sure which series fits? Send your drawing and our engineers will recommend the tool.

11 Products

Carbide Drill Bits

Solid carbide drills with internal coolant for steel, stainless steel, cast iron and high-temperature alloys.

View Products
23 Products

Carbide Milling Cutters

Carbide square and ball end mills for your production requirements.

View Products
9 Products

Carbide Taps

Ultra-fine grain tungsten carbide taps for a wide range of thread standards.

View Products
4 Products

Carbon Fiber Milling Cutters

Ultra-fine grain tungsten carbide end mills for carbon fibre (CFRP) machining.

View Products
5 Products

Custom Drill Bits

Step drills and special-profile drills made to your drawings or samples.

View Products
4 Products

Custom Milling Cutters

Special-profile milling cutters made to your drawings or samples.

View Products
12 Products

Danfoss Cavity Tools

Roughing and finishing cavity tools for Danfoss-compatible cartridge valve cavities.

View Products
3 Products

Deep-Hole Drill Bits

Carbide drills for deep holes with stable chip evacuation and straightness.

View Products
11 Products

Gear Shaper Cutters

Grade A pinion-type and disc-type gear shaper cutters in M35 cobalt HSS with TiAlN coating, for finishing and pre-shaving internal and external gears, per GB/T 6081 and DIN 3968.

View Products
12 Products

High-Precision Reamers

Carbide, cermet and welded reamers for high-precision and deep-hole bores.

View Products
1 Products

HSS Milling Cutters

High-speed steel milling cutters for general and interrupted machining.

View Products
21 Products

HSS Taps

HSS and HSS-E spiral flute, straight flute and forming taps.

View Products
4 Products

HydraForce Cavity Tools

Roughing and finishing cavity tools for HydraForce-compatible cartridge valve cavities.

View Products
8 Products

ISO 1179 Port Tools (BSPP)

Port forming cutters for ISO 1179 BSPP (G thread) ports.

View Products
4 Products

ISO 6149 Port Tools (Metric)

Port contour cutters for ISO 6149 metric thread ports.

View Products
8 Products

Orthopedic Thread Milling Cutters

Thread mills for titanium alloy and stainless steel orthopedic locking plates.

View Products
6 Products

Parker Cavity Tools

Roughing and finishing cavity tools for Parker-compatible cartridge valve cavities.

View Products
2 Products

Plastic Cutting Tools

Carbide and HSSE end mills for engineering plastics, acrylics and composites.

View Products
5 Products

SAE J1926 Port Tools (UNF)

Port contour cutters for SAE J1926 straight thread O-ring ports.

View Products
16 Products

Sun Hydraulics Cavity Tools

Roughing and finishing cavity tools for Sun Hydraulics-compatible cartridge valve cavities.

View Products
3 Products

T-Slot Milling Cutters

T-slot and undercut cutters for slots, grooves and keyways.

View Products
23 Products

Thread Milling Cutters

Tungsten carbide thread mills for a wide range of thread standards.

View Products
11 Products

Ultrasonic Blades

Ultrasonic cutting blades for honeycomb cores, prepregs and soft composites. Made to order to your drawings.

View Products
38 Products

Cavity Tools

Complete range of cavity form tools compatible with Sun Hydraulics, HydraForce, Parker and Bosch Rexroth cartridge valve standards.

View Products
17 Products

Composite Material Machining

PCD tipped and diamond coated tools designed for clean, delamination-free machining of carbon fiber, GFRP and other composite stacks.

View Products
11 Products

Gear Tools

Precision gear cutting tools including hobs, shaper cutters and form milling cutters for spur, helical and spline applications.

View Products
31 Products

Hole Making Tools

Solid carbide drills, indexable drills, reamers and boring bars engineered for tight tolerance hole production in hydraulic manifolds and valve bodies.

View Products
31 Products

Milling Cutters

High performance milling cutters with TiAlN and AlTiN coatings for steel, stainless and superalloy machining.

View Products
17 Products

Port Tools

Single-pass port tools producing complete port form, chamfer and thread relief in one operation. Available in all major hydraulic standards.

View Products
61 Products

Threading Tools

Complete threading program including taps, solid carbide thread mills and indexable inserts for UN, metric, NPT and BSPP threads.

View Products

No products listed in this category yet

We are still adding this range to our online catalog. These tools are available made to order: send your drawing or sample and we will quote sizes, lead time and price, or contact our team for current availability.

Made to Order

Manufactured to your drawing

Tools in this category are produced on request to your drawing, sample or specification. Send us your requirements and our engineers will reply within 24 hours.

Request a QuoteBrowse All Products
FT100 carbide tap series card

FT100 Carbide Straight Flute Thread Cutting Taps (M)

GOST Cutting Taps. The TY118E carbide cutting tap, with its excellent chip removal performance, high hardness and wear resistance, and machining efficiency, is particularly suitable for thread machining of high-strength, difficult-to-machine materials. Standard sizes and custom tools made to your drawings.
FT102 carbide tap series card

FT102 German Standard Threaded Straight Groove Tap

DIN13 German standard. The FT102 carbide cutting tap, with its excellent chip removal performance, high hardness and wear resistance, and machining efficiency, is particularly suitable for thread machining of high-strength, difficult-to-machine materials. Standard sizes and custom tools made to your drawings.
FT103 carbide tap series card

FT103 Japanese Standard Thread Straight Flute Tap

JIS B 0201 Japanese. The FT103 is a professional-grade straight flute tap designed for Japanese thread tapping. Standard sizes and custom tools made to your drawings.
FT104 hss tap series card

FT104 American Standard Spiral Edge HSS-E-PM Cutting Taps

American Standard 1/2 blind hole taps. The FT104 is a professional-grade spiral flute tap specifically designed for high-efficiency tapping of ANSI/ASME B1.1 standard threads. Standard sizes and custom tools made to your drawings.
FT109 carbide tap series card

FT109 American Standard Unified Thread Straight Flute Tap

Unified Thread. The FT109 is a professional-grade straight flute tap specifically designed for tapping ANSI/ASME B1.1 standard Unified Threads. Standard sizes and custom tools made to your drawings.
FT114 hss tap series card

FT114 Spiral Flute HSS-E-PM Cutting Taps

Machine Taps. The FT114 is a professional-grade tap specifically designed for tapping DIN 371 standard metric through holes. Standard sizes and custom tools made to your drawings.
FT117 carbide tap series card

FT117 Japanese Standard Thread Straight Flute Tap

JIS B 0201 Japanese Thread. The FT117 is a professional-grade spiral flute tap specifically designed for high-efficiency tapping of JIS B 0201 standard Japanese threads. Standard sizes and custom tools made to your drawings.
GP101 hss tap series card

GP101 Extruded Thread Taps with Micro Diameters (MF)

M metric thread tap. The GP101 is a professional-grade forming tap specifically designed for chipless tapping of GB/T 192-2003 standard metric threads (typically used for machining small-diameter threads of the MF (Unified Thread) standard). Standard sizes and custom tools made to your drawings.
GP104 hss tap series card

GP104 American Standard Spiral Edge HSS-E-PM Cutting Taps

American Standard 1/2 blind hole taps. The GP104 is a professional-grade spiral flute tap specifically designed for high-efficiency tapping of ANSI/ASME B1.1 standard threads. Standard sizes and custom tools made to your drawings.
GP105 hss tap series card

GP105 High-Efficiency Metric Extrusion Taps

UNF American Thread Taps. The GP105 is a professional-grade forming tap specifically designed for chipless tapping of metric threads according to ISO 261/ISO 68-1 standards. Standard sizes and custom tools made to your drawings.
GP115 hss tap series card

GP115 High-Efficiency Tapered Pipe Thread Taps

Pipe Thread Extrusion Tap. The GP115 is a professional-grade forming tap designed for chipless tapping of pipe threads according to GB/T 7306-200 standard. Standard sizes and custom tools made to your drawings.
HP101 carbide tap series card

HP101 Extruded Thread Taps with Micro Diameters (US)

UNF American Thread Taps. The HP101 is a professional-grade forming tap specifically designed for chipless tapping of ANSI/ASME B1.1 standard threads (typically used for machining small-diameter threads according to UN standards). Standard sizes and custom tools made to your drawings.
HP104 hss tap series card

HP104 Spiral Flute HSS-E-PM Cutting Taps

Machine Taps. The HP104 is a professional-grade spiral flute tap specifically designed for high-efficiency tapping of metric threads according to GB/T 192-2003 standards. Standard sizes and custom tools made to your drawings.
HP105 carbide tap series card

HP105 High-Efficiency Metric Thread Taps

Pipe Thread Extrusion Tap. The HP105 is a professional-grade forming tap specifically designed for chipless tapping of metric threads according to GB/T 192-2003 standard. Standard sizes and custom tools made to your drawings.
HP105U hss tap series card

HP105U American Standard Unified Thread Tap

American thread taps. The HP105U is a professional-grade forming tap specifically designed for chipless tapping of ANSI/ASME B1.1 standard threads. Standard sizes and custom tools made to your drawings.
HP106 hss tap series card

HP106 Metric Standard HSS-E-PM Cutting Taps

Spiral Point Tap. The HP106 tip tap’s main advantages lie in its efficient guiding, excellent thread accuracy, good chip removal performance, and stable machining process. Standard sizes and custom tools made to your drawings.
FAQ

Threading tools: common questions

Can't find your answer? Send your drawing and application details and our engineers will advise.

Ask an engineer
How do I choose between a straight flute, spiral point, and spiral flute tap for my application?

Tool selection depends primarily on the type of hole you are tapping:

  1. Straight Flute Taps: Ideal for short-chip materials (like cast iron) and suitable for both blind and through holes.
  2. Spiral Point Taps (Plug Taps): Designed for through holes. They push chips forward ahead of the tool, preventing clogging.
  3. Spiral Flute Taps: Crucial for blind holes. The helical flutes pull chips upward and out of the hole, minimizing the risk of chip packing and tap breakage.
What are the primary causes of tap breakage, and how can I prevent it?

Tap breakage is usually caused by inadequate chip evacuation, improper hole sizing, or misalignment. To optimize process reliability, ensure that:

  1. The pre-drill hole diameter is correct (refer to our Tap Drill Chart).
  2. High-quality tapping fluid or soluble oil is used to maximize lubricity.
  3. For tough materials like stainless steel or titanium, consider upgrading to JIAYI SEIKO's premium chipless forming taps (roll taps) or specialized coated cutting taps to eliminate chip-related failures.
What coatings and tool materials are recommended for high-volume tapping in stainless steel?

For stainless steel (such as 304/316) and other gummy materials, standard HSS taps wear out rapidly. JIAYI SEIKO recommends high-vanadium high-speed steel (HSSE-V3) or powder metallurgy cobalt HSS substrate, paired with TiAlN or CrN coatings. These advanced coatings offer exceptional heat resistance and low friction coefficients, effectively preventing built-up edge (BUE) and significantly extending tool life.

Can JIAYI SEIKO customize taps for non-standard thread profiles, tolerances, or special shank sizes?

Yes. We offer comprehensive OEM/ODM engineering services for non-standard threading applications. Whether you need custom thread profiles (e.g., specific pitch combinations, acme threads, multi-start threads), special tolerance classes (such as oversized/undersized GH limits), or extended shank lengths for hard-to-reach areas, our technical team can design and deliver the exact blueprint you need. Request a Custom Tap Consultation & Quote.
