Port forming cutters for ISO 1179 BSPP (G thread) ports.
Port Tools for ISO 228-1 Threaded Hydraulic Ports
Port tools for ISO 1179 hydraulic ports with ISO 228-1 parallel threads — developed around the required port form, sealing method, stud-end series, pre-hole, and production process.
Use the configuration that matches the controlled port form, pre-hole condition, machine capability, material, and production objective.
Combination geometry can generate the specified minor-diameter region, entry form, and spotface from a controlled pre-hole.
Solid-pilot and cutting-pilot concepts can be evaluated according to whether the pre-hole is finished before porting.
Spotface diameter, flatness, transition geometry, and surface-finish requirements must follow the approved port drawing and sealing method.
Special reach, shank, coolant, flute, and coating options can be reviewed for restricted-access manifolds and production cells.
ISO 1179 covers ports and stud ends using ISO 228-1 threads for elastomeric or metal-to-metal sealing. Because the sealing method and stud-end style affect the required entry and spotface geometry, the thread designation alone is not enough to select a port tool.
Provide the ISO 1179 part and revision, thread designation, S or L stud-end series where applicable, elastomeric or metal-to-metal sealing method, controlled port drawing, pre-hole condition, material, machine, holder, coolant, inspection requirements, and volume.
Open any tool for dimensions and drawings, or request a quote for a modified version.
